台亜系列號碼 | 最大長度 | 標準管徑 | 最高轉速 | 最大瞬間扭力 | 扭轉強度最大彈性限 | 應用範圍 |
SPICER | MAX | STANDARD | MAX | TORSIONAL | TORSIONAL | APPLICATION |
SERIES | LENGTH | TUBE SIZE | R.P.M | CAPACITY SHORT | STRENGTH MIN. | |
DURATION | ELASTIC LIMIT | |||||
1210 | 990mm | 50.8 x 1.65 | 6000 | |||
(39in) | (2"DIAx0.065") | |||||
1100mm | 63.5 x 1.65 | 54.1 kg-m | 109.2 kg-m | PASS. CAR & | ||
(43in) | (2.5"DIAx0.065") | 4700 1b-in | 9480 1b-in | MINI PICK-UP | ||
1200mm | 76.2 x 1.65 | |||||
(47in) | (3"DIAx0.065") | |||||
1310 | 1100mm | 63.5 x 1.65 | 6000 | |||
(43in) | (2.5"DIAx0.065") | 110.6 kg-m | 221.2 kg-m | PASS. CAR & | ||
1200mm | 76.2 x 1.65 | 9600 1b-in | 19200 1b-in | MINI PICK-UP | ||
(47in) | (3"DIAx0.065") |
